Description
UPVC Pipes and Fittings Manufacturer in Pakistan
We are the leading manufacturer of UPVC pipes fitting in Pakistan. UPVC Pipes Fitting is used for all plumbing purposes and are ideally suited for looping, outdoor installations & concealed pipelines. we understand and appreciate our client’s need for increased reliability, optimum quality and faster services. Our motto is “Our Excellence is Our Quality” which applies to our products, workmanship and latest technology for smooth operating of the business. As per our tradition, we will provide international standard products complying with standards ASTM D-2241 SDR Series.
Advantages of UPVC Pipes
Following are the advantages of UPVC pipes that accommodate:
* Smooth internal surface & continuous flow
Available Range
2″ to 12″ in Standard Length of 3, 4 & 6 meters.
Colour Range
* White
Dimensions of UPVC Pipes and Fittings
Standard: ASTM D-2241
| Nominal Size (Inches) | Outer Diameter (mm) | SDR-26 (mm) | SDR-32.5 (mm) | SDR-41 (mm) | SDR-64 (mm) | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | |
| 2 | 60.2 | 60.5 | 2.31 | 2.81 | 1.85 | 2.35 | – | – | – | – |
| 3 | 88.7 | 89.1 | 3.43 | 3.93 | 2.74 | 3.24 | 2.16 | 2.67 | – | – |
| 4 | 114.1 | 114.5 | 4.39 | 4.89 | 3.5 | 4.0 | 2.79 | 3.30 | 1.78 | 2.29 |
| 5 | 141.3 | 141.55 | 5.44 | 6.12 | 4.34 | 4.87 | 3.45 | 3.95 | 2.21 | 2.72 |
| 6 | 168.1 | 168.5 | 6.48 | 7.27 | 5.18 | 5.79 | 4.1 | 4.6 | 2.64 | 3.15 |
| 8 | 218.8 | 219.4 | 8.18 | 9.2 | 6.73 | 7.54 | 5.3 | 5.9 | 3.43 | 3.94 |
